Edwards nEXT Turbocart TIC - NEW

Name: Edwards nEXT Turbocart TIC - NEW
Brand: Edwards
SKU: NEW_nEXTTurbocart

Be the first to review this product

Call for Price

In stock

SKU

NEW_nEXTTurbocart

Request For Quote

Weight	121.25 lbs
Pumping Speed	42 l/s
Ultimate Pressure	< 5 x 10⁸ mbar

Dimensions

Description

Edwards nEXT Turbocart TIC Turbomolecular Vacuum Pumping Station - NEW

Edwards nEXT turbomolecular pumping stations are configurable with turbomolecular pump speeds ranging from 42 to 400 l/s and a choice of oil sealed or dry backing pumps ranging from 1 to 20 m³h^-1. All our nEXT turbomolecular pumping stations feature an integrated TIC turbo and instrument controllers offering full control of the package via a simple intuitive interface.

Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!

Specification

Pump / TIC power	100W / 200W
EXT75DX	Fast / Fast
nEXT 80W	Slow / Slow
nEXT 160W	Slow / Fast
Mains input
Electrical supply	90 to 264 V a.c. 47 to 63 Hz
Power consumption (max)	215 VA
Peak inrush current	10.3 A @ 110 V a.c. / 23.0 A @ 230 V a.c.
Earth stud	M4
Auxiliary terminals
Air cooling fan	24 V d.c. 3 W max, ACX70, ACX75 & ACX250H
Vent valve	24 V d.c. 2 W max, TAV5 & TAV6
Dimensions
Electronics housing	110 mm high x 105 mm wide x 245 mm deep
Front panel	106 mm wide x 128 mm high
Weight	3.5 kg
Operating temp	+0 ° to +40 °C
Storage temp	-30 ° to +70 °C
Max ambient operating humidity	90% RH non-condensing at 40 °C
Max operating altitude	3,000 m
Electronic Design	EN 61010-1
Electromagnetic Compatibility	EN 61326 Industrial Location, Class B Emissions
Enclosure rating	IP20

RFQ/Configuration

Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.

Edwards nEXT Turbocart TIC Turbomolecular Vacuum Pumping Station - NEW

TSJ3F1002 / TSJ3-F1-002  TIC Cart nEXT85D  CF63, nXDS15i, TAV5, 110V (US)
