Edwards nHT35 - NEW
Call for Price
In stock
SKU
NEW_nHT35
| Weight | 1587.4 lbs |
|---|---|
| Pumping Speed | 30,000 l/s |
| Ultimate Pressure | < 1 x 10-6 mbar |
Edwards nHT35 Vapour Diffusion Vacuum Pump - NEW
Edwards nHT series diffusion pumps provide stable high throughput vacuum performance. Designed for optimum energy efficiency, flexibility and low maintenance, the nHT series is the ideal solution for a variety of demanding industrial applications.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| ANSI | ISO | |
| Inlet | 35 in ANSI | 1000 ISO-K |
| Backing connection | 6 in ANSI | 200 ISO-K |
| Pumping speed | ||
| N2 | 30,000 l/s | |
| He | 42,000 l/s | |
| Ar | 26,000 l/s | |
| Gas Throughput | 36 mbar l/s | |
| Operating range | 10-1 to 10-7 | |
| Ultimate pressure (Edwards 704) | < 10-6 mbar | |
| Critical backing pressure (Edwards 704) | 5 x 10-1 mbar | |
| Heating power | 21.6 kW | |
| Heating cartridges | 18 | |
| Warm-up period | Less than 25 minutes | |
| Weight | 720 kg | |
| Recommended oil | Edwards 704 | |
| Oil | 9.0 - 11.0 l | |
| Recommended holding pump | E2M80 | |
| Recommended backing pump | E2M275, EDS300 |
| Type | Label | Description | Download |
|---|---|---|---|
|
Edwards nHT Series - NEW | Instruction Manual | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Edwards nHT35 Vapour Diffusion Vacuum Pump - NEW B31530400 / B315-30-400 nHT35 ANSI 380-415V, 230V B31532400 / B315-32-400 nHT35 ISO 380-415V, 230V B31530460 / B315-30-460 nHT35 ANSI 440-480V, 230V B31532460 / B315-32-460 nHT35 ISO 440-480V, 230V
