Edwards STP-iX455 - NEW

Call for Price

In stock
SKU
NEW_STP-iX455
Weight 36 lbs
Pumping Speed 300 l/s
Ultimate Pressure 5 x 10-8 Torr

Edwards STP-iX455 Turbomolecular Vacuum Pump - NEW

The STP-iX455 turbo-molecular pump features an innovative, magnetic bearing and motor drive system, providing a 50% reduction in vibration compared to previous generation turbo pumps. An integrated controller eliminates the need for a conventional, rack-mounted controller and interconnecting cables, and does not require water cooling.

The pump features 450 l/s pumping speed for nitrogen. The STP-iX455 is an excellent fit for electron microscope, metrology, lithography and other vibration sensitive applications.

  • Compact Design including a fully integrated controller
  • Inovative, Self-Sensing magnetic bearing system
  • Digital 5-axis control
  • Vibration levels reduced by 50% compared to the existing turbo pumps
  • Can be configured to run corrosive processes
  • Automatic Balancing System (ABS) standard
  • Automatic Vibration Reduction (AVR) standard
  • UL Listed, CE marked and SEMI® S2 compliant

Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!

Inlet flange ISO-100K / DN 100 CF
Pumping speed
    N2 300 l/s
    H2 300 l/s
Compression ratio
    N2 > 108
    H2 > 1 x 104
Ultimate pressure  6.5 x 10-6 Pa (5 x 10-8 Torr)
Max. working pressure 1.3 x 10-1 Pa
Allowable backing pressure     67 Pa
Rated speed 55,000 rpm
Starting time < 6 min
Mounting position Any orientation
Cooling method Not necessary
Backing pump 240 lmin-1
Leakage Magnetic Flux
Axial direction < 100 m/gauss
Radial direction < 100 m/gauss
Ambient temperature range 0 - 40°C
Storage temperature range -25 to 55°C

Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.

Edwards STP-iX455 Turbomolecular Vacuum Pump - NEW

P/N PT64-02-010 / PT6402010  STP-iX455  ISO-100K
P/N PT64-02-020 / PT6402020  STP-iX455  ISO-160K
P/N PT64-02-050 / PT6402050  STP-iX455  DN 100 CF
    PT64-02-060 / PT6402060  STP-iX455  DN 160 CF
