Edwards T-Station 85H Dry - NEW

Call for Price

In stock
SKU
NEW_85HDry
Weight 47 lbs
Pumping Speed 47-84 l/s
Ultimate Pressure <5 x 10-8 mbar

Edwards T-Station 85H Dry Turbomolecular Vacuum Pumping Station - NEW

The T-Station 85 turbomolecular pumping station seamlessly combines an nEXT85H turbomolecular pump with either a dry diaphragm pump or oil sealed backing pump and a simple controller, providing pumping speeds of 47 l/s to 84 l/s.

The T-Station 85 comes with an integrated Turbo and Active Gauge controller which enables single button start/stop of the system, the ability to control one of our active gauges*, vent valve* control and delayed start of the turbomolecular pump to either time or pressure if a gauge is fitted, making the T-Station 85 ideal for general laboratory needs.

Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!

Pumping speed for N2
    NW-40 47 l/s 300
    ISO / CF-63 84 l/s 300
Compression ratio for N2 > 1 x 1011
Backing pump speed 50/60 Hz       >1x1011
    XDD1 1.2 m3hr-1 (0.9 cfm) >1x1011
Ultimate pressure < 5 x 10-8 mbar
Inlet flange NW-40, ISO-63, CF-63 1.6
Exhaust flange   1.2
    XDD1 Fitted silencer or 1/8” BSP
Mass   <6x10-8
    XDD1 17 kg <5x10-10
Noise level ≤ 56 dB(A)
Leak tightness < 1 x 10-6 mbar l/s 11 mm OD nozzle or 3/8" BSP
Operating temperature range 12 to 40°C Fitted silencer or 1/8" BSP
Mass
TS300 ISO100 E2M1.5 kg 26
TS300 CF100 E2M1.5 kg 29
TS300 ISO100 XDD1 kg 21
TS300 CF100 XDD1 kg 24
Noise level db(A) <56 dB(A) ± 3dB(A) Declared dual number noise emission values in accordance with ISO4871
Leak tightness mbar l/s <1x10^-6
Operating temperature range
TS300 E2M1.5 °C +12 to +40
TS300 XDD1 °C +5 to +35
Type Label Description Download
Edwards T-Station 85 - NEW Instruction Manual Download

Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.

Edwards T-Station 85H Dry Turbomolecular Vacuum Pumping Station - NEW
