Kinney KT-505 LP - REBUILT

Call for Price

In stock
SKU
REBUILT_KT505LP
Weight 1870 lbs
Motor Power 15 hp
Pumping Speed 505 m3/h
Ultimate Pressure 1 x 10-2 torr

Kinney KT-505 LP Rotary Piston Vacuum Pump - REBUILT

  • Quiet, vibration free
  • No metal-to-metal contact
  • Ultimate pressure to 10 microns
  • Full pumping speed down to 1 Torr
  • Compact design, easy access for maintenance
  • Simple installation

Kinney is now part of MD-Kinney, which was formerly known as Tuthill Springfield.

Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!

Nominal displacement 300 cfm / 505 m3/h
Motor hp 15 hp / 11 kW
Normal pump rotation 870 rpm
Total oil capacity 10 gal / 38 l
Cooling water @ 60°F 1.5 gpm / 6 l/min
Weight 1,870 lbs / 848 kg
Max gas ballast flow 20 cfm / 34 m3/h
Typical blank-off pressure with 5% GB     2.0 Torr / 3.0 mbar
Ultimate pressure 0.010 Torr / 0.013 mbar
Typical noise Level @ 10 Torr 72 dBA
Type Label Description Download
Kinney KT-LP Series - REBUILT Installation Operation Maintenance Repair Manual Download

Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
