Leybold DIVAC 0.8 T - NEW

Call for Price

In stock
SKU
NEW_0.8T
Weight 13 lbs
Motor Power 0.07 hp
Pumping Speed 0.6 m3/h
Ultimate Pressure ≤ 2.25 x 100 Torr

Leybold DIVAC 0.8 T Dry Diaphragm Vacuum Pump - NEW

Our dry compressing backing pumps from the DIVAC T series are now supplemented by the three-stage DIVAC 1.4 HV3 and the DIVAC 3.8 HV3. Like the proven DIVAC T series, these new models also ensure a forevacuum free of hydrocarbons. Owing to their three-stage design, they provide especially within the lower pressure ranges a higher pumping speed and are therefore even better suited as backing pumps for turbomolecular pumps. But they are also used as backing pumps operating in the rough and medium vacuum range to pump clean media.

Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!

Inlet connection DN 16 ISO-KF, G 1/8" Inside thread
Outlet connection Silencer, G 1/8" Inside thread
Pumping speed 0.6 m3/h 0.4 cfm
Ultimate pressure ≤ 3.0 mbar / ≤ 2.25 Torr
Max. outlet pressure 2,000 mbar 1,500 Torr
Noise level 49 dB(A)
Mains connection 1-phase, 198-264 V, 50/60 Hz
Motor rating 50 W 0.07 hp
Rotation speed at 50 Hz 1,500 min-1 1,500 rpm
Rotation speed at 60 Hz 1,800 min-1 1,800 rpm
Motor protection rating IP 44
Admissible gas inlet temperature     +5 to +40°C +41 to +104°F
Admissible ambient temperature +5 to +40°C +41 to +104°F
Weight 5.9 kg 13.0 lbs

Specifications

Type Label Description Download
Leybold Dry Compressing Vacuum Pumps - NEW Excerpt / Catalog Part Download

Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.

Leybold DIVAC 0.8 T Dry Diaphragm Vacuum Pump - NEW

Part # 12780
