Leybold DRYVAC DVR 5000 C-I - REBUILT

Call for Price

In stock
SKU
REBUILT_DVR5000CI
Weight 2646 lbs
Motor Power 28 hp
Pumping Speed 3800 m3/h
Ultimate Pressure < 6 x 10-4 mbar

Leybold DRYVAC DVR 5000 C-I Dry Vacuum Pump - REBUILT

The DRYVAC is a new family or dry compressing vacuum pumps. Depending on the application the pumps are available with various equipment components. The DRYVAC series specially is developed for photovoltaic, display and process industry applications. All versions of the DRYVAC family are water cooled, very compact and can simply be mounted to various vacuum systems, so particularly with regard to the well-proven RUVAC WH, WS and WA series.

Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!

Inlet Connection DN 250 ISO-K
Outlet Connection DN 63 ISO-K
Max Pumping Speed 3,800 m3/h
Ultimate total pressure w/o gas ballast 5.0 x 10-4 mbar / 3.8 x 10-4 Torr
Ultimate total pressure w/ gas ballast --------------------------------------
Water Vapor Tolerance ≥ 60.0 mbar / ≥ 45.0 Torr
Water Vapor Capacity 25.0 kg/h
Operating fluid gear box Leybonol LVO 120
Operating Fluid Capacity 2.4 l
Noise Level with silencer 67 db(A)
Noise Level with exhaust pipe 67 db(A)
Cooling water consumption 360 l/h
Permissable cooling water pressure 3 - 7 bar
Permissable cooling water temperature +5 to +35°C
Cooling water consumption G 1/2", inside thread
Mains connection 3-ph, 380-480V, 50/60 Hz
Motor Rating 21.0 kW / 28.0 hp
Power consumption at ultimate pressure     ≤ 9.5 kW / ≤ 12.7 hp
Motor protection rating IP 20
Admissible ambient temperature +5 to +40°C
Weight 1,200 kg

Specifications

Type Label Description Download
Leybold DRYVAC DV/DVR Series - REBUILT Operating Instructions Download

Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.

Leybold DRYVAC DVR 5000 C-I Dry Vacuum Pump - REBUILT
