Leybold SOGEVAC SV 100 B - NEW
Call for Price
In stock
SKU
NEW_SV100B
| Weight | 203 lbs |
|---|---|
| Motor Power | 2 hp |
| Pumping Speed | 87.5 m3/h |
| Ultimate Pressure | ≤ 5 x 10-1 mbar |
Leybold SOGEVAC SV 100 B Rotary Vane Vacuum Pump - NEW
The new SOGEVAC range of rotary vane vacuum pumps is setting new standards and offers following major characteristics:
- Pumping speed (50 Hz): 87.5 m³/h
- Pumping speed (60 Hz): 105 m³/h
- Ultimate pressure: 0.5 mbar
- Compact design and small footprint
- Very low and constant noise level in any working condition
- Integrated functions, no external pipe
- No motor coupling up to SV 65 B
- Variant concept / specific customer configurations
- ATEX versions for categories 2 and 3, from SV 40 B to SV 100 B
- Simplified maintenance
All this without any concession to the high technical performance of the SOGEVAC pumps such as ultimate pressure, pump-down time, water vapor tolerance…
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Nominal Speed | |
| 50 Hz | 97.5 m3 x h-1 |
| 60 Hz | 117 m3 x h-1 |
| Pumping speed | |
| 50 Hz | 87.5 m3 x h |
| 60 Hz | 105 m3 x h |
| Ultimate partial pressure w/o gas ballast | ≤ 0.5 mbar |
| Ultimate total pressure w/ small gas ballast | ≤ 0.8 mbar |
| Ultimate total pressure w/ standard gas ballast | ≤ 1.5 mbar |
| Water vapor tolerance | |
| w/ small gas ballast | 10 mbar |
| w/ standard gas ballast | 30 mbar |
| Water vapor capacity | |
| w/ small gas ballast | 0.45 kg x h-1 |
| w/ standard gas ballast | 1.60 kg x h-1 |
| Noise level | 61 dBA |
| Motor power | 1.5 kW |
| Mains voltage | 230/400 V |
| Protection | IP 55-F |
| Leak rate | 1 x 10-3 mbar x l/s |
| Oil type / Capacity | GS77 / 2 l |
| Intake connection | 11/4 |
| Exhaust connection | 11/4 |
| Type | Label | Description | Download |
|---|---|---|---|
|
Leybold Oil Sealed - NEW | Instruction Manual | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Please note: The advertised price is subject to change depending on which configuration you choose.
Leybold SOGEVAC SV 100 B Rotary Vane Vacuum Pump - NEW Part no. 960500 / 960 500 Pumping speed: 87.5 m3/h Ultimate pressure: < 0.5 mbar Three-phase motor: 230/400V, 50Hz // 460V, 60Hz w/out gas ballast valve - w/out oil filter Operating fluid: LEYBONOL LVO 130 Part no. 960502 / 960 502 Pumping speed: 87.5 m3/h Ultimate pressure: < 0.5 mbar 3-phase motor: 230/400V, 50Hz // 460V, 60Hz w/out gas ballast valve - w/ oil filter Operating fluid: LEYBONOL LVO 130 Part no. 960501 / 960 501 Pumping speed: 87.5 m3/h Ultimate pressure: < 0.5 mbar 3-phase motor: 230/400V, 50Hz // 460V, 60Hz w/ small gas ballast valve - w/out oil filter Operating fluid: LEYBONOL LVO 130 Part no. 960511 / 960 511 Pumping speed: 87.5 m3/h Ultimate pressure: < 0.5 mbar 3-phase motor: 230/460V, 60Hz // 400V, 50Hz w/ small gas ballast valve - w/out oil filter Operating fluid: LEYBONOL LVO 130 Part no. 960521 / 960 521 Pumping speed: 87.5 m3/h Ultimate pressure: < 0.5 mbar 3-phase motor: 230/400V, 50/60Hz // 460V, 60Hz w/ small gas ballast valve - w/out oil filter Operating fluid: LEYBONOL LVO 130 Part no. 960516 / 960 516 Pumping speed: 87.5 m3/h Ultimate pressure: < 0.5 mbar 3-phase motor: 200V, 50/60Hz w/ small gas ballast valve - w/out oil filter Operating fluid: LEYBONOL LVO 150 Part no. 960503 / 960 503 Pumping speed: 87.5 m3/h Ultimate pressure: < 0.5 mbar 3-phase motor: 230/400V, 50Hz // 460V, 60Hz w/ small gas ballast valve - w/ oil filter Operating fluid: LEYBONOL LVO 130 Part no. 960513 / 960 513 Pumping speed: 87.5 m3/h Ultimate pressure: < 0.5 mbar 3-phase motor: 230/460V, 60Hz // 400V, 50Hz w/ small gas ballast valve - w/ oil filter Operating fluid: LEYBONOL LVO 130 Part no. 960523 / 960 523 Pumping speed: 87.5 m3/h Ultimate pressure: < 0.5 mbar 3-phase motor: 230/400V, 50/60Hz // 460V, 60Hz w/ small gas ballast valve - w/ oil filter Operating fluid: L'EYBONOL LVO 130 Part no. 960518 / 960 518 Pumping speed: 87.5 m3/h Ultimate pressure: < 0.5 mbar 3-phase motor: 200V, 50/60Hz w/ small gas ballast valve - w/ oil filter Operating fluid: LEYBONOL LVO 150 Part no. 960505 / 960 505 Pumping speed: 87.5 m3/h Ultimate pressure: < 0.5 mbar 3-phase motor: 230/400V, 50Hz // 460V, 60Hz w/ standard gas ballast valve - w/out oil filter Operating fluid: LEYBONOL LVO 130 Part no. 960512 / 960 512 Pumping speed: 87.5 m3/h Ultimate pressure: < 0.5 mbar 3-phase motor: 230/460V, 60Hz // 400V, 50Hz w/ standard gas ballast valve - w/out oil filter Operating fluid: LEYBONOL LVO 130 Part no. 960522 / 960 522 Pumping speed: 87.5 m3/h Ultimate pressure: < 0.5 mbar 3-phase motor: 230/400V, 50/60Hz // 460V, 60Hz w/ standard gas ballast valve - w/out oil filter Operating fluid: LEYBONOL LVO 130 Part no. 960517 / 960 517 Pumping speed: 87.5 m3/h Ultimate pressure: < 0.5 mbar 3-phase motor: 200V, 50/60Hz w/ standard gas ballast valve - w/out oil filter Operating fluid: LEYBONOL LVO 150 Part no. 960507 / 960 507 Pumping speed: 87.5 m3/h Ultimate pressure: < 0.5 mbar 3-phase motor: 230/400V, 50Hz // 460V, 60Hz w/ standard gas ballast valve - w/ oil filter Operating fluid: LEYBONOL LVO 130 Part no. 960514 / 960 514 Pumping speed: 87.5 m3/h Ultimate pressure: < 0.5 mbar 3-phase motor: 230/460V, 60Hz // 400V, 50Hz w/ standard gas ballast valve - w/ oil filter Operating fluid: LEYBONOL LVO 130 Part no. 960524 / 960 524 Pumping speed: 87.5 m3/h Ultimate pressure: < 0.5 mbar 3-phase motor: 230/400V, 50/60Hz // 460V, 60Hz w/ standard gas ballast valve - w/ oil filter Operating fluid: LEYBONOL LVO 130 Part no. 960519 / 960 519 Pumping speed: 87.5 m3/h Ultimate pressure: < 0.5 mbar 3-phase motor: 200V, 50/60Hz w/ standard gas ballast valve - w/ oil filter Operating fluid: LEYBONOL LVO 150 Atlas Copco GVS 100A 3-phase 230/380/460V 50/60Hz
