M-D Pneumatics PD Plus 7000 - NEW

Call for Price

In stock
SKU
NEW_7000PD

M-D Pneumatics PD Plus 7000 Rotary Positive Displacement Blower - NEW

Model PD Plus 7000 heavy duty industrial blowers are designed for high performance applications, up to 18 PSIG pressure boost or 17” Hg dry vacuum (24” Hg water injected).

Vertical & Horizontal Air Flow
This series has wide application in pneumatic conveying, wastewater treatment, and the general process industry where high pressure, high volume air is required. Seal areas are vented to atmosphere to relieve process pressure against the internal lip seals, and to provide oil-free air.

Vertical & Horizontal Single Envelope Gas Service
This series is utilized in such applications as closed loop pneumatic conveying, fuel or process gas handling, or elevated pressure applications up to 100 PSIG discharge. Vent openings are tapped and plugged to prevent gas leakage. These fittings can also accept an inert gas purge for positive containment of the process gas.

Vertical & Horizontal Double Envelope Gas Service
This series is built to laboratory standards where virtually complete sealing is required. In addition to the features shown on the single envelope series, the drive shaft is mechanically sealed and the oil sumps are plugged to provide an even higher degree of leakage protection.

M-D Pneumatics is now part of MD-Kinney, which was formerly known as Tuthill Springfield.

Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!

Type Label Description Download
M-D Pneumatics PD Plus 7000 - NEW OPERATOR’S MANUAL Download

Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.

M-D Pneumatics PD Plus 7000 Rotary Positive Displacement Blower - NEW

7010
7013
7017
7021
7026
