Pfeiffer SplitFlow 80 Neo - NEW
Call for Price
In stock
SKU
NEW_SplitFlow80Neo
| Weight | 7.5 lbs |
|---|---|
| Pumping Speed | 67 l/s |
| Ultimate Pressure | 5 x 10-10 mbar |
Pfeiffer Vacuum SplitFlow 80 Neo Turbomolecular Pump - NEW
Features include:
- Minimal space requirement due to compact design
- High pumping speed and maximum compression for all gases
- Integrated drive electronics, suitable for industrial environments - Protection class IP 54
- UL/CSA certification
- Maximum operational reliability due to integrated rotor temperature measurement
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| I/O interfaces | RS485, remote |
| Sound pressure level (EN ISO 2151) | 48 dB(A) |
| Run-up time | 1.25 min |
| Pumping speed for Ar | 66 l/s |
| Pumping speed for H2 | 48 l/s |
| Pumping speed for He | 58 l/s |
| Pumping speed for N2 | 67 l/s |
| Gas throughput at final rotational speed for Ar | 0.54 hPa x l/s |
| Gas throughput at final rotational speed for H2 | 15.3 hPa x l/s |
| Gas throughput at final rotational speed for He | 2.7 hPa x l/s |
| Gas throughput at final rotational speed for N2 | 1.3 hPa x l/s |
| Compression ratio for Ar | 1 x 1011 |
| Compression ratio for H2 | 1.4 x 105 |
| Compression ratio for He | 1.3 x 107 |
| Compression ratio for N2 | 1 x 1011 |
| Forevacuum max. for N2 | 22 hPa (mbar) |
| Mounting orientation | Arbitrary |
| Weight | 1.7 kg |
| Gas inlet / outlet | DN40/DN 63 ISO-K/ISO-KF/CF-F / G 1/4" |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Pfeiffer Vacuum SplitFlow 80 Neo Turbomolecular Pump - NEW
(BUSCH P/N)
PMP73000210 / PM P730 002 10 / 2000091715 SplitFlow 80 Neo TC 80, DN 63 CF-F
PMP73000510 / PM P730 005 10 / 2000208161 SplitFlow 80 Neo TC 80, DN 63 CF-F w/ turned venting connection
PMP73000110 / PM P730 001 10 / 2000103707 SplitFlow 80 Neo TC 80, DN 63 ISO-K
