Welch DuoSeal 1397B - NEW

Call for Price

SKU
NEW_1397B

Welch Gardner Denver DuoSeal 1397B Rotary Vane Vacuum Pump - NEW

Belt-Drive Vacuum Pump

  • High contamination tolerance
  • Ultimate vacuum < 0.001 Torr
  • Low RPM for long service life

Applications: Vacuum Ovens, Glove Boxes, General Laboratory Vacuum

Motor Power (HP): 1

Ultimate Pressure (Torr): 0.00013

Pumping Speed (cfm): 17.7

Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!

Applications Vacuum ovens, glove boxes, general lab vacuum
Type Belt drive vacuum pump
Free air displacement 17.7 cfm (500 l/min)
Ultimate pressure 1 x 10-4 (0.00013)
Pump RPM 400
Oil capacity 1.25 l
Motor horsepower 1 (750 watts)
Adjustable vac / gas ballast     Yes
Tubing needed 13/16 (21)
Intake thread 1-20 NPT
Exhaust thread 1-20 NPT
Weight 132 lbs
Type Label Description Download
Welch DuoSeal 1374B | 1397B Instruction Manual Download

Request for Quote

Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs. Please follow the above link, and fill out the quote form.

Welch Gardner Denver DuoSeal 1397B Rotary Vane Vacuum Pump - NEW

1397B01 / 1397B-01  115V 60Hz single-phase
1397M01 / 1397M-01  230-460V 60Hz 3-phase
