Agilent Turbo-V 1001 Navigator Controller - NEW

Starting at $5,060
In stock
Only %1 left
SKU
NEW_TV1001NC
Weight 11.90 lbs

Agilent Varian Turbo-V 1001 Navigator Controller - NEW

The Turbo-V 1001 Navigator onboard controller is designed to operate the Turbo-V 1001 turbomolecular pump. The onboard controller mounts at the bottom of the turbo pump or near by, and controls pump parameters and accessories such as vent valves or the air cooling fan.

Capable of running on worldwide voltage, the Turbo-V 1001 Navigator can be operated remotely using Agilent A-Plus software, or integrated into an existing system via an analog or serial interface.

  • Compact onboard mounting design allows easy integration
  • Ready for Vacuum Link app to enable full pump control through your mobile phone
  • RS232/RS485 communication protocols (and optional Profibus interface) for easy data management
  • Remote control with A-plus software enables pump operation, control, and recording of system parameters
  • Vent valve and cooling fan driving to give full vacuum system control
  • Universal voltage (100–240 V) enables worldwide operation

Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!

Configuration
  • Onboard controller
For Pump Type
  • Turbo Pump
Maximum Pump Cable Length
  • 100 m
Operating Environment Relative Humidity
  • 90 % maximum non condensing humidity
Operating Environment Temperature
  • 5° C to 45° C
Pump Model Compatibility
  • Turbo-V 1001 Navigator Pump
Standards and Certifications
  • UNI EN 292-1
  • UNI EN 292-2
  • EN-CENELEC 55011
  • IEC 1000-4-2 (ex 801-2)
  • IEC 1000-4-3 (ex 801-3)
  • IEC 1000-4-4 (ex 801-4)
  • EN 61010-1 (IEC 1010-1)
  • EN 1012-2
Weight
  • 5.4 kg

Specs

Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.

Agilent Varian Turbo-V 1001 Navigator Controller - NEW

9698978 Turbo-V 1001 Navigator controller
