EBARA EV-A10 - NEW

Call for Price

In stock
SKU
NEW_EV-A10
Weight 159 lbs
Pumping Speed 1,000 l/min
Ultimate Pressure 1 x 10-2 mbar

EBARA EV-A10 Air-Cooled Dry Vacuum Pump - NEW

The Model EV-A10 air-cooled dry pump offers industry leading specifications in an air cooled dry pump. The pump comes standard with four lockable casters/levelers.

Features

  • Small air-cooling pump
  • No-contact design
  • High pumping speeds at atmosphere
  • Highest water vapor pumping of any air-cooled dry pump
  • UL, CE, and NRTL rated
  • Single- and three-phase versions available

Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!

Max pumping speed 1,000 l/min
Atmospheric open pumping speed 800 l/min
Ultimate pressure w/o gas ballast 1.0 Pa
Ultimate pressure w/ gas ballast 2.0
Max inlet pressure Atmospheric pressure
Max water vapor pumping rate 500 g/hr
Inlet connection NW40
Outlet connection NW25
Approx. power at ultimate pressure     1.1 kW
Weight 72 kg / 159 lbs

Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.

EBARA EV-A10 Air-Cooled Dry Vacuum Pump - NEW

EV-A10-2-P / EVA102P  1-phase 200V
EV-A10-3U-P / EVA103UP  3-phase 200V
