Edwards iH1800 - NEW

Call for Price

In stock
Weight 1107 lbs
Motor Power 9.4 hp
Pumping Speed 1,800 m3h-1
Ultimate Pressure 7.5x 10-4 torr

Edwards iH1800 Semiconductor Dry Vacuum Pump - NEW

Edwards advanced semiconductor vacuum pumps have been field-proven to perform to the highest operating standards. Reliability and high performance are achieved by extending service life, improving uptime and increasing productivity, while minimizing footprint and cost of ownership.

The iH Series offers high reliability for difficult processes, such as PECVD and LPCVD, where particulate, condensable and corrosive by-products are present.

Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!

Peak speed 1,800 m3h-1
1,060 cfm
30,000 lmin-1
Ultimate vacuum 1 x 10-3 mbar
7.5 x 10-4 Torr
0.1 Pa
Typical shaft seal nitrogen flow 4 slm
Inlet connection ISO160
Outlet connection NW40
Typical cooling water flow at 15 psi pressure drop     240 lh-1
4 lmin-1
Weight 502 kg
Power input at ultimate 4.1 kW
Rated motor power 7.0 kW
Oil capacity 1.6 l

All figures are typical without gas ballast.


Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.

Edwards iH1800 Semiconductor Dry Vacuum Pump - NEW

A59040908 / A590-40-908  iH1800  460V 60Hz three-phase
A59040945 / A590-40-945  iH1800  200/208V 60Hz 3-phase
A59040946 / A590-40-946  iH1800  380/415V 50Hz 3-phase
A59040957 / A590-40-957  iH1800  230V 60Hz 3-phase
A59060945 / A590-60-945  iH1800  200/208V 50Hz 3-phase
A59042908 / A590-42-908  iH1800HTX  460V 60Hz 3-phase
A59042945 / A590-42-945  iH1800HTX  200/208V 50/60Hz 3-phase
A59042946 / A590-42-946  iH1800HTX  380/415V 50Hz 3-phase
A59042957 / A590-42-957  iH1800HTX  230V 60Hz 3-phase
A59062945 / A590-62-945  iH1800HTX  200/208V 50/60Hz 3-phase
