Edwards iH1000 - NEW

Call for Price

In stock
Weight 948 lbs
Motor Power 8.2 hp
Pumping Speed 1,000 m3h-1
Ultimate Pressure 7.5x 10-4 torr

Edwards iH1000 Semiconductor Dry Vacuum Pump - NEW

Edwards advanced semiconductor vacuum pumps have been field-proven to perform to the highest operating standards. Reliability and high performance are achieved by extending service life, improving uptime and increasing productivity, while minimizing footprint and cost of ownership.

The iH Series offers high reliability for difficult processes, such as PECVD and LPCVD, where particulate, condensable and corrosive by-products are present.

Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!

Peak speed 1,000 m3h-1
589 cfm
16,670 lmin-1
Ultimate vacuum 1 x 10-3 mbar
7.5 x 10-4 Torr
0.1 Pa
Typical shaft seal nitrogen flow 4 slm
Inlet connection ISO100
Outlet connection NW40
Typical cooling water flow at 15 psi pressure drop     240 lh-1
4 lmin-1
Weight 430 kg
Power input at ultimate 3.8 kW
Rated motor power 6.1 kW
Oil capacity 1.48 l

All figures are typical without gas ballast.


Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.

Edwards iH1000 Semiconductor Dry Vacuum Pump - NEW

A59030908 / A590-30-908  iH1000  460V 60Hz three-phase
A59030945 / A590-30-945  iH1000  200/208V 50/60Hz 3-phase
A59030946 / A590-30-946  iH1000  380/415V 50Hz 3-phase
A59030957 / A590-30-957  iH1000  230V 60Hz 3-phase
