Agilent HLD BR15 Bench Helium Mass Spectrometer Leak Detector - NEW

The Agilent HLD BR15 leak detector uses a mass spectrometer tuned to detect helium, which is used as a tracer gas to locate and/or measure very small leaks in enclosed devices or systems. The HLD BR15 is both a precise instrument and a robust workhorse, featuring an easy-to-use touch screen interface and menu structure that quickly connect users to powerful leak detection capabilities. Built-in application setups shorten test cycles, and setups can be saved to assure repeatability. It fits easily on a table or bench, and includes an Agilent DS-302 rotary vane pump, with a pumping speed of 15 m3/hour, for rapid evacuation of test parts and systems and rapid clean-up of ambient helium between test cycles. Hardware required to connect the DS-302 to the HLD BR15 is also included, allowing the pump to be mounted on the floor or where convenient.

Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!

Model PD03 PR02 BD15 MD15 BR15 MR15 BR30 MR30 BD30 MD30
Primary pump and pumping speed IDP-3
DS 40M
DS 302
DS 602
TriScroll 620
Detectable mass 4
Pumping speed for helium 1.8 l/s
Sensitivity 5 x 10-12 mbar•l/s
Display range 10-4 - 10-11
Maximum test port pressure 13 mbar
Wireless remote
Eight languages Chinese, English, French, German, Japanese, Korean, Russian, Spanish
Analog, RS232 and discrete IO interface options
Type Label Description Download
Agilent G8610A - G8612D Series - NEW Operation Manual Download

Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.

Agilent HLD BR15 G8612A Bench Helium Mass Spectrometer Leak Detector - NEW

G8612-64000  115 VAC  9.0/5.4 Amp  50/60 Hz
G8612-64001  230 VAC  4.4/2.5 Amp  50/60 Hz

PHD-4 Sniffer
HLD Wireless Remote
